DIY Outdoor Kitchen POWER Burner Cutout Kit (not a drop down kit)

cutout range 15.75"to 22.5"

Features new Telescoping cutout parts

Description:

This item is the extra tubes and connectors needed to make a power burner cutout into the top of your module frame

including our Amazing No Cut Connectors and no cut telescoping tubes for below and behind the side burner.

 This is not a drop down kit where you want the power burner to be 12" below the counter top.

 It will work for all built-in power burners with a 15 3/4-22 1/2"  wide cutout width that are supported on

the counter top such as Bull, Cal Flame, Fire Magic, Summerset, Napolean, etc...

Some high end slide in power burners will require you to make a platform frame in addition to this cutout opening.

For platform side burners you will buy extra tubes and one way connectors sold as a side burner platform kit in addition to this universal grill kit.

INCLUDES:

 2 ea  Steel Tubes  12"x21mm

 2 ea Steel Tubes   14"x25mm

 2ea  CTT tubes 28 3/4" for left and right side of burner

 2ea  3 Way Corner Couplers

 4ea 1 Way couplers ( 2 males and 2 females)

Note: You will use the two vertical tubes from the module for the right and left side burner supports.

These will connect to the included 3 way corner couplers leaving you two extra one way couplers that you will use for the CTT's saving you money.

NOT INCLUDED

actual appliance, module, screws, cement board, etc.

Same Assembly as our grill cutout kit
